Mini-Change Cordsets
MECHANICAL
Connector Face:
Molded Body Material:
O-Ring:
Coupling Nut:
Cable:


Option:



Outside Diameter:
3/C
4/C
5/C
ELECTRICAL
Voltage Rating:
Amperage:


ENVIRONMENTAL
Protection:
Ambient Operating Temp:

CERTIFICATION
UL:







PBT
TPE
Viton
Nickel-Plated Brass
Yellow PVC Cable Jacket,
#24 AWG Over 19 X #36 Copper
Stranding, UL Style 2661
Yellow, High-Flex PUR Cable
Jacket, #24 AWG Over
128 X #44 Stranding,
UL Style 20233
PVC PUR
0.17" 0.18"
0.18" 0.18"
0.20" 0.20"

60V AC / 75V DC
3P - 4A
4P - 4A
5P - 3A

NEMA 6P, IP 68
-4° TO 221°F - PVC
-4° TO 176°F - PUR

UL Recognized, File NO. E152210







Part Number Selector
  3P 4P 5P
FEMALE FACE
VIEW
COLOR CODE 1 - brown 2 - blue 3 - black 1 - brown2 - white3 - blue4 - black 1 - brown2 - white3 - blue4 - black 5 - gray
VOLTAGE 60V AC / 75V DC 60V AC / 75V DC 60V AC / 75V DC
CURRENT 4A 4A 3A
CONDUCTOR #24-3 #24-4 #24-5
CLICK ON A PART NUMBER FOR MORE OPTIONS
FEMALE SINGLE-ENDED CORDSETS WITH 2 METER PVC CABLE
STRAIGHT 403000A10M020 404000A10M020 405000A10M020
90° 403001A10M020 404001A10M020 405001A10M020
MATING RECEP. 4R3P06A27C300 4R4P06A27C300 4R5P06A27C300
MALE SINGLE-ENDED CORDSETS WITH 2 METER PVC CABLE
STRAIGHT 403006A10M020 404006A10M020 405006A10M020
90° 403007A10M020 404007A10M020 405007A10M020
MATING RECEP. 4R3P00A27C300 4R4P00A27C300 4R5P00A27C300
