POWER

CORDSETS

Request Quote
Micro-Change Cordsets
MECHANICAL
Closure Caps
Single Keyway M12
Metallic:
Non-Metallic:

Dual Keyway
Metallic:

Dual Keyway Adapters
Adapter Face:
Adapter Body:
Conductors:


















Black Anodized Aluminum
Nylon 6/6


Gray Anodized Aluminum


PVC
Gray Anodized Aluminum
#22 AWG with IRR. PVC
Insulation Over 7 X #30 COP
Per Stranding, 300V,
UL Style 1430, CSA REW









Part Number Selector
MICRO-CHANGE SINGLE KEYWAY M12 ACCESSORIES
DESCRIPTION 3P 4P 5P
METALLIC CLOSURE
CAP WITH INTERNAL
THREADS
80011
METALLIC CLOSURE
CAP WITH EXTERNAL
THREADS
80015
NON-METALLIC
CLOSURE CAP WITH
EXTERNAL THREADS
80013
CLICK ON A PART NUMBER FOR MORE OPTIONS
MICRO-CHANGE DUAL KEYWAY 1/2" - 20 UNF ACCESSORIES
DESCRIPTION 2P 3P 4P 5P 6P
ADAPTER WITH
1/2 - 20 MALE
DUAL KEY TO
FEMALE MINICHANGE
70004 70204 70404 70604 -
ADAPTER WITH
1/2 - 20 FEMALE
DUAL KEY TO
MALE MINICHANGE
70005 70205 70405 70605 -
METALLIC
CLOSURE CAP
WITH INTERNAL
THREADS
70010
METALLIC
CLOSURE CAP
WITH EXTERNAL
THREADS
70015
