Other-Molded | Safety Plugs | 2 & 4 Poles
Provide Electrical Lock-Outs During Machine Maintenance
Color-Coded Configurations To Assist In Safety Lock-Out
Fit Standard FS or FD Boxes
| MECHANICAL |
| Shorting Plug |
| Body: |
| Contact: |
| Chain Yoke: |
| Angle Receptacle |
| Housing & Body: |
| Contact: |
| Cast Receptacle |
| Housing: |
| Contact: |
| Insert: |
| Gasket: |
| ELECTRICAL |
| Voltage Rating: |
| Amperage: |
| ENVIRONMENTAL |
| Ambient Oper. Temp: |
| CERTIFICATIONS |
| UL: |
| CSA: |
| Nitrile/PVC Compound |
| Brass, Solid |
| Zinc-Plated Steel |
| Nitrile/PVC Compound |
| Brass |
| Aluminum |
| Brass |
| Nitrile/PVC |
| Neoprene |
| 600V AC/DC |
| 25A |
| -4° TO 194° F (-20° TO 90° C) |
| UL Recognized, File NO. E46237 |
| CSA Certified, File NO. LR6837 |
Part Number Selector
| 2P | 2P | 4P | |
| MALE FACE VIEW |
 |
 |
 |
| COLOR | Yellow | Red | Orange |
| VOLTAGE | 600V AC/DC | 600V AC/DC | 600V AC/DC |
| CURRENT | 25A | 25A | 25A |
| CLICK ON A PART NUMBER FOR MORE OPTIONS | |||
| MALE SHORTING PLUGS | |||
| 1' CHAIN | 22803 | 22904 | 43302 |
| 2' CHAIN | 22804 | 22905 | 43303 |
| 3' CHAIN | 22805 | 22906 | 43304 |
| FEMALE RECEPTACLES | |||
| ANGLE RECEP. | 22801 | 22903 | 43301 |
| CAST RECEP. ASSEMBLY | 22806 | 22902 | 43305 |
| CLICK ON A PART NUMBER FOR MORE OPTIONS | |||
| SUB-ASSEMBLIES AND MISCELLANEOUS COMPONENTS | |||
| INSERT FOR CAST ASSEMBLY | 22802 | 22901 | - |
| INSERT W/ MOUNTING SHELL | 22807 | 22907 | - |
